Developing Interactive Tools with R-Shiny

class: center, middle, inverse, title-slide

.title[
# Developing Interactive Tools with R-Shiny
]
.subtitle[
## <a href="https://eligurarie.github.io/EFB654/">EFB 654: R and Reproducible Research</a>
]
.author[
### Elie Gurarie
]
.date[
### April 1, 2026
]

---

class: inverse, middle

# Uses of Shiny Apps

.pull-left-70.Large[

- **Data exploration** — interact with your own datasets in real time

- **Simulation manipulation** — adjust parameters and see results instantly

- **Sharing results** — no R required for the end user

- **Making tools accessible** — wrap complex analyses in a simple interface
]

.pull-right-30[
![](https://rstudio.github.io/shiny/reference/figures/logo.png)

]

---
class: inverse, middle, center

# Gallery: https://shiny.posit.co/r/gallery/

---
class: inverse, middle, center

# Structure of a Shiny App

---

## Two Essential Pieces

Every Shiny app has exactly **two components**:

.pull-left[
### `ui` — User Interface
- What the user **sees**
- Defines layout, inputs, and output placeholders
- Built with layout and widget functions
]

.pull-right[
### `server` — Server Function
- What R **does**
- Reacts to inputs
- Renders outputs back to the UI
- Always: `function(input, output)`
]

```r
shinyApp(ui = ui, server = server)
```

> These two are **linked by matching IDs** — output names in `ui` must match what `server` renders.

---

## The Flow of a Shiny App

.pull-left.large[
```
User changes input  →
   input$id updates  →
      server reacts  →
          output$id re-renders  →
             UI updates
```
]

.pull-right[

- **Reactive** — outputs automatically update when inputs change

- **IDs are the glue** — every input and output has a unique string ID

- `input$bins` in the server reads the widget named `"bins"` in the UI

- `output$distPlot` in the server fills the placeholder named `"distPlot"` in the UI
]

---

## Anatomy of `app.R`

.pull-left-60[
```r
library(shiny)

ui <- fluidPage( # defines the page layout
 titlePanel("..."), # title at top
 sidebarLayout( # two-column layout
 sidebarPanel(...), # LEFT: inputs go here
 mainPanel(...) # RIGHT: outputs go here
 )
)

server <- function(input, output) {
 output$myPlot <- renderPlot({
 # code that uses input$... to make a plot
 })
}

shinyApp(ui = ui, server = server)
```
]

.pull-right-40[

``` r
hist(faithful[,2])
```

]

---

## Old Faithful App:  .small[`  File -> New File -> Shiny Web App`]
.pull-left.small[

#### User Input

```r
ui <- fluidPage(
 titlePanel("Old Faithful Geyser Data"),
 sidebarLayout(
 sidebarPanel(
 sliderInput("bins", # input ID
 "Number of bins:",
 min = 1,
 max = 50,
 value = 30) # default value
 ),
 mainPanel(
 plotOutput("distPlot") # output ID placeholder
)))
```

| Element | Role |
|---|---|
| **input**: | `sliderInput` with ID `"bins"` |
| **output**: | `plotOutput` with ID `"distPlot"` |
]

.pull-right.small[

#### Server Side

```r
server <- function(input, output) {

output$distPlot <- renderPlot({
 # generate bins based on input$bins from ui.R
 x <- faithful[, 2]
 bins <- seq(min(x), max(x), length.out = input$bins + 1)

# draw the histogram with the specified number of bins
        hist(x, breaks = bins, col = 'darkgray', border = 'white',
             xlab = 'Waiting time to next eruption (in mins)',
             main = 'Histogram of waiting times')
    })
}
```

| Element | Role |
|---|---|
| `input$bins` | reads the slider value |
| `renderPlot({})` | wraps plotting code; re-renders on every input change |
| `output$distPlot` | sends the plot to the UI placeholder |

]

---

## ID Matching

.pull-left[
**In `ui`:**
```r
sliderInput("bins", ...)

plotOutput("distPlot")
```
]

.pull-right[
**In `server`:**
```r
input$bins

output$distPlot <- renderPlot({...})
```
]

| UI function | creates/displays | Server counterpart |
|---|---|---|
| `sliderInput("bins", ...)` | input widget | `input$bins` |
| `plotOutput("distPlot")` | output placeholder | `output$distPlot <- renderPlot({})` |

> **IDs must match exactly** — spelling and capitalization matter.

---
class: inverse, large

# Practice

.pull-left-60.Large[
1. Make the Old Faithful Shiny App work
 - click on **Run** or run the `shinyApp(ui = ui, server = server)`

2. Modify the title of the Shiny App - to include your name - and re-run it.

]

.pull-right-40[ ![](animaltraining.jpg)
]

---
class: inverse, middle, center

# Adding Inputs

---

## Some useful options:

| Function | What it creates | Returns |
|---|---|---|
| `sliderInput()` | Slider bar | numeric |
| `numericInput()` | Number entry box | numeric |
| `textInput()` | Text box | character |
| `selectInput()` | Dropdown menu | character |
| `radioButtons()` | Radio button group | character |
| `checkboxInput()` | Single checkbox | logical |
| `checkboxGroupInput()` | Multiple checkboxes | character vector |
| `colorInput()` | Color picker | hex string |

All share the same first two arguments: **`inputId`**, **`label`**

---

## `numericInput()` — Control the Y-axis

Add a numeric input for `ylim` in the sidebar:

```r
numericInput("ymax",
             "Y-axis maximum:",
             value = 40,
             min = 1,
             max = 200)
```

Use it in the server:

```r
hist(x, breaks = bins,
 col = 'darkgray', border = 'white',
 ylim = c(0, input$ymax), # <-- reactive y limit
 xlab = 'Waiting time (mins)',
 main = 'Histogram of waiting times')
```

---

## `selectInput()` — Choose a Color

Add a dropdown for histogram color:

```r
selectInput("color",
            "Bar color:",
            choices = c("darkgray", "steelblue", "tomato",
                        "forestgreen", "goldenrod"),
            selected = "darkgray")
```

Use it in the server:

```r
hist(x, breaks = bins,
 col = input$color, # <-- reactive color
 border = 'white',
 ylim = c(0, input$ymax),
 xlab = 'Waiting time (mins)',
 main = 'Histogram of waiting times')
```

---

## `app2.R` — Full Updated App

.small[
```r
library(shiny)

ui <- fluidPage(
 titlePanel("Old Faithful Geyser Data"),
 sidebarLayout(
 sidebarPanel(

 sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30), # <- note commas!

 numericInput("ymax", "Y-axis maximum:", value = 40, min = 1, max = 200),

 selectInput("color", "Bar color:",
 choices = c("darkgray", "steelblue", "tomato",
 "forestgreen", "goldenrod"),
 selected = "darkgray")
 ),
 mainPanel(
 plotOutput("distPlot")
 )
 )
)

server <- function(input, output) {
 output$distPlot <- renderPlot({
 x <- faithful[, 2]
 bins <- seq(min(x), max(x), length.out = input$bins + 1)
 hist(x, breaks = bins,
 col = input$color, border = 'white',
 ylim = c(0, input$ymax),
 xlab = 'Waiting time to next eruption (in mins)',
 main = 'Histogram of waiting times')
 })
}

shinyApp(ui = ui, server = server)
```
]

---
class: inverse, large

# Practice Adding Inputs

.pull-left-60.Large[

Add a `selectInput()` flag that chooses whether to plot the histogram of the `$waiting` column or the `eruptions` column.

- **To make it easy:**  The `ui()` line will look like this:

```r
selectInput("column", "What to plot:",
             choices = c("eruptions", "waiting"),
             selected = "eruptions")
```

]

.pull-right-40[ ![](animaltraining.jpg)
]

**Now - how do you modify the `server` function?**

---
class: inverse, middle, center

# Output Types

---

## **Output Types:** Common Output Functions

Every output needs a **UI placeholder** and a **server renderer** — they always come in pairs:

| UI (placeholder) | Server (renderer) | Produces |
|---|---|---|
| `plotOutput()` | `renderPlot({})` | plot |
| `textOutput()` | `renderText({})` | inline text |
| `verbatimTextOutput()` | `renderPrint({})` | console-style output |
| `tableOutput()` | `renderTable({})` | simple HTML table |
| `dataTableOutput()` | `renderDT({})` | interactive table (`DT` package) |
| `uiOutput()` | `renderUI({})` | dynamically generated UI |

---

## `renderPrint` — Console-Style Output

Show `summary(faithful)` reactively — useful for model output, `str()`, etc.

.pull-left[
**UI:**
```r
verbatimTextOutput("stats")
```
]

.pull-right[
**Server:**
```r
output$stats <- renderPrint({
 x <- faithful,[input$column]
 summary(x)
})
```
]

- `verbatimTextOutput` preserves monospace formatting
- `renderPrint` captures anything that would print to the console
- Works with `summary()`, `str()`, `print()`, model objects, etc.

---

## `renderText` — Reactive Inline Text

Show a summary sentence that updates with the slider:

.pull-left[
**UI:**
```r
mainPanel(
 plotOutput("distPlot"),
 textOutput("summary") # <- add below plot
)
```
]

.pull-right[
**Server:**
```r
output$summary <- renderText({
 x <- faithful[, 2]
 bins <- seq(min(x), max(x),
 length.out = input$bins + 1)
 counts <- hist(x, breaks = bins, plot = FALSE)$counts

 paste("Showing", input$bins, "bins.",
 "Largest bin count:", max(counts))
})
```
]

> `renderText` returns a **single string**. Use `paste()` or `paste0()` to build it.

---

## `app4.R` — Plot + Summary + Stats

.small[
```r
library(shiny)
ui <- fluidPage(
 titlePanel("Old Faithful Geyser Data"),
 sidebarLayout(
 sidebarPanel(
 sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30),
 numericInput("ymax", "Y-axis maximum:", value = 40, min = 1, max = 200),
 selectInput("column", "What to plot:",
 choices = c("eruptions", "waiting"),
 selected = "eruptions"),
 ),

 mainPanel(
 plotOutput("distPlot"),
 textOutput("summary"),
 verbatimTextOutput("stats")
 )
 )
)
server <- function(input, output) {
 output$distPlot <- renderPlot({
 x <- faithful[, input$column]
 bins <- seq(min(x), max(x), length.out = input$bins + 1)
 hist(x, breaks = bins,
 col = "grey", border = 'darkgrey',
 ylim = c(0, input$ymax),
 xlab = ifelse(input$column == "column",
 'Waiting time to next eruption (mins)',
 "Duration of eruptions (min)"),
 main = 'Histogram of waiting times')
 })

 output$summary <- renderText({
 x <- faithful[,input$column]
 bins <- seq(min(x), max(x),
 length.out = input$bins + 1)
 counts <- hist(x, breaks = bins, plot = FALSE)$counts

 paste("Showing", input$bins, "bins.",
 "Largest bin count:", max(counts))
 })

 output$stats <- renderPrint({
 x <- faithful[,input$column]
 summary(x)
 })
}
shinyApp(ui = ui, server = server)
```
]

---
class: inverse, large

# Practice

.pull-left-60.Large[

Starting from `app4.R`:

Add a `textOutput` that reports how many observations fall **above the mean** for the selected variable.

]

.pull-right-40[ ![](animaltraining.jpg) ]

---
class: inverse, middle, center

# Multiple Outputs with Tabs

---

## `tabsetPanel` — Organizing Outputs

Instead of stacking outputs vertically in `mainPanel`, wrap them in tabs:

.pull-left[
**Before:**
```r
mainPanel(
  plotOutput("distPlot"),
  textOutput("summary"),
  verbatimTextOutput("stats")
)
```
]

.pull-right[
**After:**
```r
mainPanel(
  tabsetPanel(
    tabPanel("Plot",    plotOutput("distPlot")),
    tabPanel("Summary", textOutput("summary"),
                        verbatimTextOutput("stats"))
  )
)
```
]

- `tabsetPanel` wraps any number of `tabPanel()` calls
- Each `tabPanel` takes a **label** then any UI elements
- The server side is **unchanged** — same `output$` names

---

## Separate Tabs per Variable

Rather than a dropdown to switch variables, give each its own tab:

```r
mainPanel(
  tabsetPanel(
    tabPanel("Waiting Time",
             plotOutput("waitPlot"),
             verbatimTextOutput("waitStats")),
    tabPanel("Eruption Duration",
             plotOutput("eruptPlot"),
             verbatimTextOutput("eruptStats"))
  )
)
```

Now the **sidebar controls** (bins, color) apply to **both** tabs — and the server renders all four outputs independently.

---

## `app5.R` — Two Variable Tabs

.small[
```r
library(shiny)

ui <- fluidPage(
 titlePanel("Old Faithful Geyser Data"),
 sidebarLayout(
 sidebarPanel(
 sliderInput("bins", "Number of bins:", min = 1, max = 50, value = 30),
 selectInput("color", "Bar color:",
 choices = c("darkgray", "steelblue", "tomato",
 "forestgreen", "goldenrod"),
 selected = "darkgray")
 ),
 mainPanel(
 tabsetPanel(
 tabPanel("Waiting Time",
 plotOutput("waitPlot"),
 verbatimTextOutput("waitStats")),
 tabPanel("Eruption Duration",
 plotOutput("eruptPlot"),
 verbatimTextOutput("eruptStats"))
 )
 )
 )
)

server <- function(input, output) {

output$waitPlot <- renderPlot({
 x <- faithful$waiting
 bins <- seq(min(x), max(x), length.out = input$bins + 1)
 hist(x, breaks = bins, col = input$color, border = "white",
 xlab = "Waiting time (mins)", main = "Waiting Time")
 })

output$eruptPlot <- renderPlot({
 x <- faithful$eruptions
 bins <- seq(min(x), max(x), length.out = input$bins + 1)
 hist(x, breaks = bins, col = input$color, border = "white",
 xlab = "Eruption duration (mins)", main = "Eruption Duration")
 })

output$waitStats <- renderPrint({ summary(faithful$waiting) })
 output$eruptStats <- renderPrint({ summary(faithful$eruptions) })
}

shinyApp(ui = ui, server = server)
```
]

---
class: inverse, large

# Practice adding tabs

.pull-left-60.large[

Add a **third tab** called `"Scatter Plot"` that plots eruption duration vs. waiting time.

- UI: add a third `tabPanel` with a `plotOutput("scatterPlot")`

- Server: add `output$scatterPlot <- renderPlot({...})` using `plot(faithful$waiting, faithful$eruptions, ...)`

**Bonus:** make the point color respond to `input$color`

]

.pull-right-40[ ![](animaltraining.jpg) ]

---
class: inverse, middle, center

# Shiny Apps Inside R Markdown

---

## Two Ways to Share a Shiny App

| Approach | How | Requires R? |
|---|---|---|
| Standalone `app.R` | Run in RStudio or deploy to `shinyapps.io` | Yes |
| Embedded in `.Rmd` | One line in YAML; widgets live inside the document | Yes (to view) |

Embedding is useful when you want **narrative + interactivity together** — e.g., a report where the reader can explore the data themselves.

---

## The One Required Change: YAML

Add `runtime: shiny` to your document's YAML header:

```yaml
---
title: "Old Faithful Explorer"
output: html_document
runtime: shiny
---
```

> - This turns a normal knitted HTML into a **live Shiny document**
> - It can no longer be knitted to a static file — it must be **Run** (RStudio shows "Run Document" instead of "Knit")
> - Requires R to be running to view — not a standalone HTML

---

# Old Faithful Rmd

.pull-left-70[

```` r
---
title: "Old Faithful Explorer"
output: html_document
runtime: shiny
---

Let's explore Old Faithful eruption durations and intervals!

```{r, echo = FALSE}
shinyAppFile("app5.R")
```

This is old Faithful when it was a teeny bit less old:

![](https://upload.wikimedia.org/wikipedia/commons/6/60/Old_Faithful%2C_William_Henry_Jackson.jpg)
````
]

.pull-right-30[
![](https://upload.wikimedia.org/wikipedia/commons/6/60/Old_Faithful%2C_William_Henry_Jackson.jpg)
]

---

##  Deploying to shinyapps.io

So far your app only runs **locally** — only you can see it. Deploying pushes it to a server so anyone with a link can use it, no R required.

**[shinyapps.io](https://www.shinyapps.io)** — free hosting for Shiny apps (Posit's service)

**One-time setup:**

```r
install.packages("rsconnect")
```

1. Create a free account at **shinyapps.io**

2. In RStudio: *Tools → Global Options → Publishing → Connect* — paste in your account token

3. That's it.

---

## Deploying

With your `app.R` open in RStudio, **Click:** the blue **Publish** button (top right of the script pane)

RStudio bundles your app files, uploads them, and gives you a URL:

```
https://yourusername.shinyapps.io/yourappname/
```

- Free tier allows **5 apps** and **25 active hours/month**

- To update: just run `deployApp()` again — it overwrites

- To share: send the URL — recipient needs no R, no RStudio

Shiny Rmd documents (with `runtime: shiny`) deploy the **same way** — just publish the `.Rmd` file instead of `app.R`

> my shinyapps:  https://www.shinyapps.io/admin/#/dashboard

---
class: inverse

# Final thoughts

.Large[

- Shiny apps can be Extremely Powerful - for **exploration**, **education** and **communication**

- Just about nything anyone can put onto a webpage, you can add.  Is *"infinitely customizable"* - with an R engine underneath.

- **But** the code can be very clunky, fussy, confusing, hard to learn, .red[hard to debug].  So much precise matching of parentheses / brackets / commas / semi-colots.

- You will save yourself **A LOT** of time [*and - if you're concerned about the environment - a lot of Google-search energy*] if you let an LLM  like `Claude.ai` help you out.
]

---

# Prompting Claude to Extend `app5.R`

.pull-left[
### Example prompt:

> `See shiny app called app5.R. Add features:`

> `1. Scatter plot tab showing eruptions vs. waiting time with fitted regression line and R² displayed`

> `2. Interactive data table tab showing raw faithful data`

> `3. Download button for the currently displayed plot as PNG`

]

.pull-right[
### Tips for prompting:

- **Always paste the full code** — no context = bad output

- **Ask for one feature at a time**.
  - Prepare to iterate frequently, don't delete old versions.

- **Ask it to explain** any new functions it introduces

- If something breaks: *"Here is the error: [paste]. Fix it."*

- Always ***understand what it is doing!***

]
